Digital Forecast Bridge M_OTRS Bidirectional Optical to HD/SDI Micro Type Converter

Bridge M_OTR is a device to transmit up to 10Km by converting to Optical signal of 3 SDI signal one of SMPTE standards. It consists of Bridge M_OTR TX with the received Bridge M_OTR RX to send, it works in pairs.

Key Features

• Bidirectional Optical to HD/SDI
• 1310nm ,1490nm,1550nm FP-LD Source
• 2 HD/SDI Select input ( Send SD/HD/3G )
• 1 HD/SDI Receive out ( Receive part )
• SMPTE Mode(Support Pathological Signal)
• Up to 10 Km using Single mode fiber
• DC 5V ~ 17V wide operating range

Technical Specifications

Physical
Dimension (W x H x D)
78 x 59.2 x 20 (mm)
Weight
90g
Power Level
+12 VDC
Power Consumption
3 Watts (Max : 4Watts)
Humidity
0 to 95% RH, non-condensing
Optic
SMPTE compliance Optical SFP ( Max 3 GHz )
Single mode , 1310nm/1490nm/1550nm
Up to 10Km
Supports multi-rate SDI formats
SMPTE 125M
NTSC (480i 59.94), PAL (576i 50)
SMPTE 296M
720p (60/59.94/50)
SMPTE-274M,SMPTE-292M
1080i (60/59.94/50)
1080p (30/29.97/25/24/23.98)
SMPTE-424M
1080p (60/59.94) 3G
