Name: 1000uF 16VDC Low ESR Electrolytic Capacitor Buy Cheap Best Store To Get
SKU: 1000uF 16VDC Low ESR Electrolytic Capacitor Buy Cheap Best Store To Get-1902
Availability: InStock

1000uF 16VDC Low ESR Electrolytic Capacitor Buy Cheap Best Store To Get

$1.08

SKU: 1000uF 16VDC Low ESR Electrolytic Capacitor Buy Cheap Best Store To Get-1902 Categories: Industrial Electrical, Passive Components

An electrolytic capacitor uses an electrolyte (a liquid or gel containing a high concentration of ions) to achieve a large capacitance than the other capacitor types. These electrolytic capacitors are polarized, meaning that the voltage on the positive terminal must always be greater than the voltage on the negative terminal. They are commonly used as filters in devices in various power supplies to reduce the voltage ripple as well as input and output smoothing as an LPF.

Features:

– Stable, low impedance characteristics
– Ripple Current mA rms: 1400
– Ripple current measured at 105°C 100kHz
– Impedance: 0.046
– Impedance: max at 20°C 100kHz
– Low D.C. leakage current
– Extended life – high reliability withstanding 2,000 to 4,000 hours load life at 105°C
– Radial leads on standard pitch

Specifications

Height	20mm
Diameter	10mm
Capacitor type	Electrolytic Low ESR
Polarised Capacitor
Operating Temperature	105°C
Item capacitance	1000µF
DC Voltage	16V
Component Type	Electrolytic Capacitor
Passive marking code	Printed
Passive number of legs	2
Component package	Radial
Passive connector type	Solder Legs
Passive mount type	Through Hole
Pack Quantity	1pc
